All the static spirals are logarithmic spirals in nature, except for Archimedes spiral.Some authors define this spiral as the combination of the curves r and. Other spirals that fall into this group are the Fermat’s spiral and the hyperbolic spiral. The Archimedes spiral (or spiral of Archimedes) is a kind of Archimedean spiral. The normal one occurs when in its equation, n = 1. Usually the term Archimedean spiral is used for more general spirals.If we take the mirror image of this arm along Y axis, the other arm will be obtained. These two arms are connected to the origin. Archimedes created an invention called the Archimedes screw, which is effectively one of the earliest types of pumps used to move water. An Archimedes spiral, there are two arms – one arm for θ> 0 and another for θ In Archimedes spiral, any ray passing through the origin does intersect successive turns of the spiral with a constant distance which is equal to 2 π Therefore, it is also named “arithmetic spiral”. Archimedean spirals of black color with ten turnings of two arms of arithmetic spirals, rotating with constant angular.The characteristics of the Archimedean spiral are: Image shows central beam divided into 8 parts, then wood is fixed around the entire length at equal distances forming a spiral channel. This curve is used in the tooth profiles of the gear hob. This curve is used to ensure the continuity of the tooth profile during the resharpening.įor a resharpening with a zero-rake angle, the cutting profile lies on a plane that passes through the hob axis and the Archimedean spiral must ensure that the profiles that are on this perpendicular section are constant. The Archimedean spiral is a curve traced out by a point moving in such a way that its movement towards or away from the center is uniform with the increase of its vectorially angle from the starting line.
An important element of the gear hob design is the tip which represents a relief of the tooth profile and a part of the Archimedean spiral. This page shows the spiral of Archimedes (Archimedean spiral, arithmetic spiral) given by the following equation in polar coordinates (, ).
